Extraction Thimbles, Cellulose 15x50 mm (ID x H)

Product
$109.90 USD Qty:



Catalogue # WCT5003
Comparable To Thomas Brand 1229C25
Filters/Pack 25
Price/Filter $4.40

Wyvern's extraction thimbles have been proven for their purity and consistent high quality. The thimbles are widely used in Soxhlet extraction units by companies such as FOSS, Gerhardt GmbH, B├╝chi and others providing a safe, convenient and efficient method of solvent extraction of solids and semi-solids.

Thimble sizes should be selected carefully to fit extractors correctly. The different sizes represent the established practice of showing the internal diameter and overall length of the thimble in millimetres. Therefore, an extra allowance for wall thickness should be made when calculating external diameters. The thimble should pass through the narrower end of the upper extractor socket, allowing 1-2 mm clearance, and be 5-10 mm above the level of the top of the siphon tube

    General Features:
  • Wide selection of sizes
  • Most Soxhlet extractor sizes
  • Consistent wall thickness
  • High purity glass binderless microfiber
  • High purity cellulose fibers
    General Applications
  • Soxhlet extraction
  • Air and waste gas analysis
  • Collection of solid particles such as dust
  • Smoke stack gas monitoring
  • Analysis of pesticide residues
  • Oil/fat content of solid foods
  • Oil & grease analysis of solid wastes
  • Elution for biochemical analysis
    Common Cellulose Applications
  • Fat determination of meat and diary products
  • Determination of PCB in fish products
  • Determination of free fats in food products
  • Determination of pesticide residues in food products
  • Extraction of plasticizers from PVC
  • Extraction of dioxins
  • Solid particle such as dust collection in air flows
  • Evaluation of liquid content in concrete slurry
